| DIMENSI | |||
| Panjang Keseluruhan | mm | 1.930 | |
| Lebar Keseluruhan | mm | 655 | |
| Tinggi Keseluruhan | mm | 1.050 | |
| Jarak Antara As Roda | mm | 1.240 | |
| Jarak Mesin ke Tanah | mm | 140 | |
| Berat Motor | kg | 100 | |
| Tinggi Tempat Duduk | mm | 755 | |
| MESIN | |||
| Jenis Mesin | 4 tak, SOHC | ||
| Sistem Pendinginan | Pendingin Udara | ||
| Sistem Starter | Listrik dan Engkol | ||
| Sistem Pelumasan | SALCS (Suzuki Advanced) | ||
| Karburator | Mikuni VM 18SH | ||
| Silinder x Langkah Piston | 51.0 x 55.2 | ||
| Kapasitas mesin | cc | 113 | |
| Daya Maksimum | ps/rpm | 8.4/8,000 | |
| Torsi Maksimum | Nm/rpm | 8.9/5,000 | |
| Perbandingan Kompresi | 9.5 : 1 | ||
| RANGKA | |||
| Ukuran Ban Depan | 70/90-17M/C 38P | ||
| Ukuran Ban Belakang | 80/90-17M/C 44P | ||
| Velg | Jari-jari | ||
| Rem Depan | Tromol | ||
| Rem Belakang | Tromol | ||
| Kapasitas Bagasi | L | 8 | |
| SISTEM LISTRIK | |||
| Jenis Pengapian | Suzuki DC-CDI | ||
| Busi | NGK C6 HSA/ ND U 20 FS-U | ||
| Accu | 12 Volt / 5 Ah | ||
| KAPASITAS | |||
| Kapasitas Tangki Bensin | L | 4,3 | |
| Oli Mesin (Penggantian) | ml | 800 | |
| Oli Mesin - (Pembongkaran) | ml | 1000 | |
